Features:
mechanical structure
1.High strength tubular bracket structure,give the body full load stability.
2.Internal mixer platform and welded reinforced steel plate(vehicles) on both ends of the extended edition, suitable for long body, high strength/resistance to deformation.
3.Tee mixer import high pressure ball valve, sealed performance is good,no inner leakage, ensure the main cylinder and synchronicity.
4.Mixer shaft parts built-in oil free bushing.
5.Mixer adopts pneumatic safety lock structure,(with synchronous unlock insurance device).
Drive mode:
Double hydraulic oil cylinder(tandem master cylinder)
hydraulic  system
1.Maixer oil cylinder adopt the new rolling process cylinder/combined seal.
2.Except oil cylinder mechanical overload trip protection, add limit stroke electric protection, dual protection of the hydraulic system.
3.Hydraulic work pieces of high qulality hydraulic pump station, provide a stable supply(with overload protection)
Electrical system
1.24v safety voltage control, through the control cabinet panel control up/down/pneumatic unlock.
2.Mechanical safety lock plate set synchronous monitoring switch, to ensure that biateral bridge plate unlock rear can fall at the same time, prevent accident risk of wehicle overturn
3.Safety voltage control circuit, ensure use safety
4.Mixer options bilateral unbalanced bridge plate photoelectric control accessories
